Service Column
S-210

Supply Specifications

S-210-P

SERVICE COLUMN ART. S-210 in Aisi 304 Stainless Steel with dimensions cm. 63x46x120, thickness 12/10. It performs the control function for the sump washing by means of a TIMED PUSH BUTTON.
Column equipped with:
- drinking water supply system via tap (or faucet)
- no. 1 tap (or faucet) for cassette cleaning
- instructions in Italian and English
- control unit / control panel / control board
- perimeter insulation
==> WITH CALEFFI BALLSTOP ANTI-CONTAMINATION VALVES (or BACKFLOW PREVENTION VALVES)
==> WITH CHECK VALVE (or NON-RETURN VALVE).

S-210-F

SERVICE COLUMN ART. S-210 in Aisi 304 Stainless Steel with dimensions cm. 63x46x120, thickness 12/10. It performs the control function for the sump washing by means of a PHOTOCELL (or PHOTOCELL SENSOR) that detects the vehicle upon entry (pre-wash) and exit (tank wash rinse).
(the photocell must be positioned in front of the sump for correct vehicle detection)
Column equipped with:
- drinking water supply system via tap (or faucet)
- no. 1 tap (or faucet) for cassette cleaning
- instructions in Italian and English
- control unit / control panel / control board
- perimeter insulation
==> WITH CALEFFI BALLSTOP ANTI-CONTAMINATION VALVES (or BACKFLOW PREVENTION VALVES)
==> WITH CHECK VALVE (or NON-RETURN VALVE).

Accessories

S-210-RUB_ACC

EXPOSED TAP FOR ART. S-210 with protection for drinking water supply, complete with water system and internal piping.

S-210-TUBO-P_ACC

CASSETTE DRAIN OPTION FOR ART. S-210
WITH DRAIN PIPE
extractable cassette drainage system,
self-cleaning by means of no. 1 nozzle installed
inside, activated by push button.
Complete with internal piping.

S-210-TUBO-F_ACC

CASSETTE DRAIN OPTION FOR ART. S-210
WITH DRAIN PIPE
extractable cassette drainage system,
self-cleaning by means of no. 1 nozzle installed
inside, activated by photocell.
Complete with internal piping.

S-210-T_ACC

ANCHORAGE FRAME FOR ART. S-210 for installation in galvanized sheet metal with adjustable feet for leveling, complete with inspectable siphon. Diam. 100 mm.

S-210-ICE_ACC

ICE HEATING SYSTEM FOR ART. S-210 composed of a constant wattage (or constant power) heating cable with a thermostat, which will maintain the minimum operating temperature to prevent ice formation and the consequent breakage of the pipes;
- buttons for tap (or faucet) solenoid valve activation.

R-PRES_ACC

PRESSURE TAP WITH HOSE CONNECTOR with complete 1/2" water system FOR CASSETTE RINSING.
(Not compatible with ICE opt. - Not compatible with payment system)

WC-LED-2_ACC

PERIMETER LED LIGHTING KIT.
